• Neuf

Kit d'accessoires de contrôle d'accès Hikvision DS-KAS-7M01

Référence: DS-KAS-7M01

716,67 DH
livraison sous 24H ou 48H Max

Kit d'accessoires de contrôle d'accès Hikvision DS-KAS-7M01

Quantité

Ajouter au favoris



Paiement sécurisé



Livraison Rapide



Garantie

  • Power supply
  • Input: 110 to 230 VAC
  • Output: 12 VDC, 24 W
  • Momentary current: 5 A
  • Persistent current: 5 A
  • Support backup battery charging and discharging
  • Button
  • Stainless steel panel
  • LED indicator
  • Magnetic lock
  • Lock dimension: L * W * H: 250 mm * 28 mm * 48 mm (9.8" * 1.1" * 1.9")
  • Holding force: Max. 272 kg (600 Lbs)
  • Lock bracket
  • Suitable for magnetic lock
  • L bracket dimensions: L * W * H: 250 mm * 46 mm *30 mm (9.8" * 1.8" *1.2")
  • Z bracket dimensions: L * W * H: 180 mm * 47 mm * 47 mm (7.1" * 1.9" * 1.9")

  • Power Supply/General
  • ModelDS-K7M-AW24
  • Power supply

    Power input: 110 to 230 VAC

    Power output: 12 VDC, 24 W

  • Power consumption

    Power output: 24 W

    Momentary current: 5 A

    Persistent current: 2 A

  • Working temperature-10 °C to 50 °C (14 °F to 122 °F)
  • Working humidity＜ 95%
  • Dimensions168 mm × 216 mm × 73.3 mm
  • Magnetic Lock/General
  • ModelDS-K4H255S
  • Maximum holding forceMax. 272 kg (600 Lbs)
  • Power supply12 VDC, 470 mA - 24 VDC, 235 mA
  • Working temperature-10 °C to 55 °C (14 °F to 131 °F)
  • Working humidity0 to 90% (Relative humidity)
  • Dimensions

    Lock Body: L×W×H: 250 mm × 28 mm × 48 mm (9.8" × 1.1\" × 1.9\")

    Armature Plate: L×W×H: 180 mm × 38 mm × 12 mm (7.1 × 1.5\" × 0.5\")"

  • Door typeWooden door, glass door, and metal Door
  • Shell performanceHard Anodizing electroplating operated
  • Lock bodyEco-friendly Zinc electroplating operated
  • Armature plateEco-friendly Zinc electroplating operated
  • Bracket of Magnetic Lock/General
  • ModelDS-K4H255-LZ
  • Dimensions

    L-bracket Dimension (L×W×H): 250×46×30mm (9.8×1.8×1.2");

    Z-bracket Dimension (L×W×H): 180×47×47mm (7.1×1.9×1.9)"

  • Suitable DoorWooden door, glass door, and metal door
  • Shell performanceHigh strength aluminum alloy surface sandblasting oxidation
  • Exit Button/General
  • ModelDS-K7P07
  • Power supply12 to 24 VDC
  • Working temperature-20 °C to 55 °C (-4 °F to 131 °F)
  • Working humidity0 to 95% (Relative humidity)
  • Dimensions115 mm × 70 mm × 16 mm (4.53" × 2.76" × 0.63")
  • MaterialPanel: stainless steel
