• Camera
• Image Sensor :1/2.4" Progressive Scan CMOS
• Max. Resolution :3200 × 1800
• Min. Illumination :Color: 0.005 Lux @ (F1.6, AGC ON),B/W: 0 Lux with IR
• Shutter Time :1/3 s to 1/100,000 s
• Day & Night :IR cut filter
• Angle Adjustment :Pan: 0° to 355°,tilt: 0° to 70°,rotate: 0° to 355°

• Lens
• Lens Type :Varifocal lens, motorized lens, 2.8 to 12 mm
• Focal Length & FOV :2.8 to 12 mm, horizontal FOV 106° to 35.6°, vertical FOV 55.9° to 20°, diagonal FOV 127.4° to 40.8°
• Lens Mount :Ø14
• Iris Type :Fixed
• Aperture :F1.6

• DORI
• DORI: 68 to 200 m, O: 27 to 79 m, R: 13.6 to 40 m, I: 6.8 to 20 m

• Illuminator
• Supplement Light Type :IR,White Light
• Smart Supplement Light :Yes
• IR Wavelength :850 nm

• Video
• Main Stream :

50 Hz:

20 fps (3200 × 1800, 2688 × 1520, 1920 × 1080, 1280 × 720)

60 Hz:

20 fps (3200 × 1800, 2688 × 1520, 1920 × 1080, 1280 × 720)

• Sub-Stream :

50 Hz: 20 fps (1280 × 720, 640 × 480, 640 × 360)

60 Hz: 20 fps (1280 × 720, 640 × 480, 640 × 360)

• Video Compression :

Main stream: H.265+/H.265/H.264+/H.264,

Sub-stream: H.265/H.264/MJPEG

• Video Bit Rate :32 Kbps to 16 Mbps
• H.264 Type :Baseline Profile,Main Profile,High Profile
• H.265 Type :Main Profile
• Bit Rate Control :CBR,VBR
• Scalable Video Coding (SVC) :H.264 and H.265 encoding
• Region of Interest (ROI) :1 fixed region for main stream

• Audio
• Audio Type :Mono sound
• Audio Compression :G.711ulaw/G.711alaw/G.722.1/G.726/MP2L2/PCM/AAC-LC
• Audio Bit Rate :64 Kbps (G.711ulaw/G.711alaw)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 to 160 Kbps (MP2L2)/16 to 64 Kbps (AAC-LC)
• Audio Sampling Rate :8 kHz/16 kHz
• Environment Noise Filtering :Yes

• Network
• Protocols :TCP/IP, ICMP, DHCP, DNS, HTTP, RTP, RTSP, NTP, IGMP, IPv6, UDP, QoS, FTP, SMTP, UPnP
• Simultaneous Live View :Up to 6 channels
• API :Open Network Video Interface (Profile S, Profile G, Profile T),ISAPI,SDK
• Security :Password protection, complicated password, watermark, basic and digest authentication for HTTP, WSSE and digest authentication for Open Network Video Interface, security audit log, host authentication (MAC address)
• User/Host :

Up to 32 users

3 user levels: administrator, operator, and user

• Client :iVMS-4200,Hik-Connect
• Web Browser :

Plug-in required live view: IE 10, IE 11,

Local service: Chrome 57.0+, Firefox 52.0+, Edge 89+

• Image
• Image Settings :Rotate mode,saturation,brightness,contrast,sharpness,gain,white balance,adjustable by client software or web browser
• Day/Night Switch :Day,Night,Auto,Schedule
• Wide Dynamic Range (WDR) :120 dB
• SNR≥ 52 dB
• Image Enhancement :BLC,HLC,3D DNR
• Privacy Mask :4 programmable polygon privacy masks

• Interface
• Ethernet Interface :1 RJ45 10 M/100 M self-adaptive Ethernet port
• On-Board Storage :Built-in memory card slot, support microSD/microSDHC/microSDXC card, up to 512 GB
• Built-in Microphone :Yes
• Audio :

-S: 1 input (line in), two-core terminal block, max. input amplitude: 3.3 Vpp, input impedance: 4.7 KΩ, interface type: non-equilibrium

-S: 1 output (line out), two-core terminal block, max. output amplitude: 3.3 Vpp, output impedance: 100 Ω, interface type: non-equilibrium

• Alarm :-S: 1 input, 1 output (max. 12 VDC, 30 mA)
• Reset Key :Yes

• Event
• Basic Event : Motion detection (support alarm triggering by specified target types (human and vehicle)),video tampering alarm,exception
• Linkage :Upload to FTP/memory card, notify surveillance center, send email, trigger recording, trigger capture, trigger alarm output (-S),audible warning

• General
• Power :

12 VDC ± 25%, 0.88 A, max. 10.5 W,Ø5.5 mm coaxial power plug,reverse polarity protection,

PoE: IEEE 802.3af, Class 3, max. 12 W

• Material :Metal & Plastic
• Dimension :

Ø105 mm × 252 mm (Ø4.1 × 9.9\")"

• Package Dimension :315 mm × 137 mm × 141 mm (5.5" × 5.5" × 6.1")
• Weight :Approx. 750 g (1.7 lb.)
• With Package Weight :Approx. 1075 g (2.4 lb.)
• Storage Conditions :-30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)
• Startup and Operating Conditions :-30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)
• Language :English, Ukrainian
• General Function :Heartbeat, anti-banding, mirror, password protection,password reset by email

• Approval
• EMC :

CE-EMC: EN 55032:2015+A1:2020, EN 50130-4:2011+A1:2014, EN IEC 61000-3-2:2019+A1:2021, EN 61000-3-3:2013+A1:2019+A2:2021,

RCM: AS/NZS CISPR 32: 2015,

IC: ICES-003: Issue 7

• Safety :

UL: UL 62368-1,

CB: IEC 62368-1: 2014+A11,

CE-LVD: EN 62368-1: 2014/A11: 2017,

BIS: IS 13252 (Part 1): 2010/IEC 60950-1: 2005

• Environment :

CE-RoHS: 2011/65/EU,

WEEE: 2012/19/EU,

Reach: Regulation (EC) No 1907/2006

• Protection :IP67: IEC 60529-2013
