Camera

• Image Sensor :1/3″ Progressive Scan CMOS
• Max. Resolution :2688 × 1520
• Min. Illumination :Color: 0.005 Lux @ (F1.6, AGC ON), 0 Lux with IR on
• Shutter Time :1/3 s to 1/100,000 s
• Day & Night :IR cut filter
• Angle Adjustment :Pan: 0° to 360°, tilt: 0° to 90°, rotate: 0° to 360°

 Lens

• Focal Length & FOV :2.8 to 12 mm, horizontal FOV 95.8° to 29.2°, vertical FOV 50.6° to 16.4°, diagonal FOV 114.6° to 33.4°
• Lens Mount :Ø14
• Iris Type :Fixed
• Aperture :F1.6

 DORI

• DORI :2.8 to 12 mm: D: 64 m to 200 m, O: 25.4 m to 79.4 m, R: 12.8 m to 40 m, I: 6.4 m to 20 m

 Illuminator

• Supplement Light Type :IR
• Supplement Light Range :Up to 60 m
• Smart Supplement Light :Yes
• IR Wavelength :850 nm

 Video

• Main Stream :

50Hz: 25 fps (2688 × 1520, 1920 × 1080, 1280 × 720)

60Hz: 30 fps (2688 × 1520, 1920 × 1080, 1280 × 720)

• Sub-Stream :

50Hz: 25 fps (1280 × 720, 640 × 480, 640 × 360)

60Hz: 30 fps (1280 × 720, 640 × 480, 640 × 360)

• Third Stream :

50 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360)

60 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360)

• Video Compression :

Main stream: H.265/H.264/H.264+/H.265+

Sub-stream: H.265/H.264/MJPEG

Third stream: H.265/H.264

• Video Bit Rate :32 Kbps to 8 Mbps
• H.264 Type :Baseline Profile/Main Profile/High Profile
• H.265 Type :Main Profile
• Bit Rate Control :CBR/VBR
• Scalable Video Coding (SVC) :Yes
• Region of Interest (ROI) :1 fixed region for main stream and sub-stream

 Audio

• Audio Compression :G.711ulaw/G.711alaw/G.722.1/G.726/MP2L2/PCM/MP3/AAC-LC
• Audio Bit Rate :64 Kbps (G.711ulaw/G.711alaw)/16 Kbps (G.722.1)/16 Kbps (G.726)/16-64 Kbps (AAC-LC)/32-192 Kbps (MP2L2)/8-320 Kbps (MP3)
• Audio Sampling Rate :8 kHz/16 kHz/32 kHz/44.1 kHz/48 kHz
• Environment Noise Filtering :Yes

 Network

• Protocols :TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, NTP, UPnP, SMTP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour, SSL/TLS, PPPoE, WebSocket, WebSockets
• Simultaneous Live View :Up to 6 channels
• API :Open Network Video Interface (Profile S, Profile G), ISAPI, SDK
• User/Host :Up to 32 users. 3 user levels: administrator, operator and user
• SecurityPassword protection, complicated password, HTTPS encryption, IP address filter, Security Audit Log, basic and digest authentication for HTTP/HTTPS, TLS 1.1/1.2, WSSE and digest authentication for Open Network Video Interface
• Network Storage :NAS (NFS, SMB/CIFS), auto network replenishment (ANR)
• Client :iVMS-4200, Hik-Connect, Hik-Central
• Web Browser :

Plug-in required live view: IE 10, IE 11,

Plug-in free live view : Chrome 57.0+, Firefox 52.0+, Edge 89+,

Local service: Chrome 57.0+, Firefox 52.0+, Edge 89+


• Image Parameters Switch :Yes
• Image Settings :Rotate, mirror, privacy mask, saturation, brightness, contrast, sharpness, gain, white balance adjustable by client software or web browser
• Day/Night Switch :Day, Night, Auto, Schedule
• Wide Dynamic Range (WDR) :120 dB
• SNR :≥ 52 dB
• Image Enhancement :BLC, HLC, 3D DNR

 Interface

• Ethernet Interface :1 RJ45 10M/100M self-adaptive Ethernet port
• On-Board Storage :Built-in microSD, up to 512 GB
• Audio

1 input (line in), two-core terminal block, max. input amplitude: 3.3 vpp, input impedance: 4.7 KΩ, interface type: non-equilibrium;

1 output (line out), two-core terminal block, max. output amplitude: 3.3 vpp, output impedance: 100 Ω, interface type: non-equilibrium

• Alarm :1 input, 1 output (max. 12 VDC, 30 mA)
• Reset Key :Yes

 Event

• Basic Event : Motion detection (human and vehicle targets classification), video tampering alarm, exception
• Smart Event :

Line crossing detection, intrusion detection (support alarm triggering by specified target types (human and vehicle))

Face detection

• Linkage :Upload to FTP/memory card/NAS, notify surveillance center, trigger record, trigger capture, Email

 General

• Power :

12 VDC ± 25%, 1.08 A, max. 13 W, Ø5.5 mm coaxial power plug, reverse polarity protection

PoE: 802.3at, Class 4, 42.5 V to 57 V, 0.36 A to 0.27 A, max. 15 W

• Dimension :308.5 × 97.9 × 93 mm (12.2" × 3.9" × 3.7")
• Package Dimension :385 × 190 × 180 mm (15.2" × 7.5" × 7.1")
• Weight :Approx. 1390 g (3.1 lb.)
• With Package Weight :Approx. 1961 g (4.3 lb.)
• Storage Conditions :-30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)
• Startup and Operating Conditions :-30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)
• Language :

33 languages

English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil), Ukrainian

• General Function :Anti-flicker, heartbeat, password reset via e-mail, pixel counter

 Approval

• EMC :FCC (47 CFR Part 15, Subpart B); CE-EMC (EN 55032: 2015, EN 61000-3-2: 2014, EN 61000-3-3: 2013, EN 50130-4: 2011 +A1: 2014); RCM (AS/NZS CISPR 32: 2015); IC (ICES-003: Issue 6, 2016); KC (KN 32: 2015, KN 35: 2015)
• Safety :UL (UL 60950-1); CB (IEC 60950-1:2005 + Am 1:2009 + Am 2:2013); CE-LVD (EN 60950-1:2005 + Am 1:2009 + Am 2:2013); BIS (IS 13252(Part 1):2010+A1:2013+A2:2015)
• Environment :CE-RoHS (2011/65/EU); WEEE (2012/19/EU); Reach (Regulation (EC) No 1907/2006)
• Protection :IP67 (IEC 60529-2013), IK10 (IEC 62262: 2002)
