• Camera
• Image Sensor :1/2.4" Progressive Scan CMOS
• Max. Resolution :3200 × 1800
• Min. Illumination :Color: 0.001 Lux @ (F1.0, AGC ON),0 Lux with light
• Shutter Time :1/3 s to 1/100,000 s
• Day & Night :24/7 color imaging
• Angle Adjustment :Pan: 0° to 360°,tilt: 0° to 90°,rotate: 0° to 360°

• Lens
• Lens Type :Fixed focal lens, 2.8 and 4 mm optional
• Focal Length & FOV :

2.8 mm, horizontal FOV: 117°, vertical FOV: 64°, diagonal FOV: 138°

4 mm, horizontal FOV: 82°, vertical FOV: 45°, diagonal FOV: 95°

• Lens Mount :M12
• Iris Type :Fixed
• Aperture :F1.0
• Depth of Field :

2.8 mm: 2 m to ∞

4 mm: 3.1 m to ∞

• DORI
• DORI :

2.8 mm, D: 64 m, O: 25 m, R: 12 m, I: 6 m

4 mm, D: 92 m, O: 36 m, R: 18 m, I: 9 m

• Illuminator
• Supplement Light Type :White Light
• Supplement Light Range :Up to 30 m
• Smart Supplement Light :Yes

• Video
• Main Stream :

50 Hz:

20 fps (3200 × 1800, 2688 × 1520, 1920 × 1080, 1280 × 720)

60 Hz:

20 fps (3200 × 1800, 2688 × 1520, 1920 × 1080, 1280 × 720)

• Sub-Stream :

50 Hz: 20 fps (1280 × 720, 640 × 480, 640 × 360)

60 Hz: 20 fps (1280 × 720, 640 × 480, 640 × 360)

• Video Compression :

Main stream: H.265+/H.265/H.264+/H.264,

Sub-stream: H.265/H.264/MJPEG

• Video Bit Rate :32 Kbps to 16 Mbps
• H.264 Type :Baseline Profile,Main Profile,High Profile
• H.265 Type :Main Profile
• Bit Rate Control :CBR,VBR
• Region of Interest (ROI) :1 fixed region for main stream

• Audio
• Audio Type :-U: Mono sound
• Environment Noise Filtering :-U: Yes
• Audio Sampling Rate :-U: 8 kHz/16 kHz
• Audio Compression : -U: G.711ulaw/G.711alaw/G.722.1/G.726/MP2L2/PCM/AAC-LC
• Audio Bit Rate :-U: 64 Kbps (G.711 ulaw)/64 Kbps (G.711 alaw)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 to 160 Kbps (MP2L2)/16 to 64 Kbps (AAC-LC)

• Network
• Protocols :TCP/IP, ICMP, DHCP, DNS, HTTP, RTP, RTSP, NTP, IGMP, IPv6, UDP, QoS, FTP, SMTP, UPnP
• Simultaneous Live View :Up to 6 channels
• API :Open Network Video Interface (Profile S, Profile G (only -F model supports)),ISAPI,SDK
• User/Host :

Up to 32 users

3 user levels: administrator, operator, and user

• Security :Password protection, complicated password, watermark, basic and digest authentication for HTTP, WSSE and digest authentication for Open Network Video Interface, security audit log, host authentication (MAC address)
• Client :iVMS-4200,Hik-Connect
• Web Browser :

Plug-in required live view: IE 10, IE 11,

Local service: Chrome 57.0+, Firefox 52.0+, Edge 89+

• Image
• Image Settings :Rotate mode,saturation,brightness,contrast,sharpness,gain,white balance,adjustable by client software or web browser
• Day/Night Switch :Day,Night,Auto,Schedule
• Wide Dynamic Range (WDR) :120 dB
• SNR :≥ 52 dB
• Image Enhancement :BLC,HLC,3D DNR
• Privacy Mask :4 programmable polygon privacy masks

• Interface
• Ethernet Interface :1 RJ45 10 M/100 M self-adaptive Ethernet port
• On-Board Storage :-F: Built-in memory card slot, support microSD/microSDHC/microSDXC card, up to 512 GB
• Built-in Microphone :-U: Yes
• Reset Key :-F: Yes

• Event
• Basic Event :Motion detection (support alarm triggering by specified target types (human and vehicle)),video tampering alarm,exception
• Linkage :Upload to FTP/memory card (-F), notify surveillance center, send email, trigger recording (-F), trigger capture

• General
• Power :12 VDC ± 25%, 0.45 A, max. 5.5 W,Ø5.5 mm coaxial power plug,reverse polarity protection,PoE: IEEE 802.3af, Class 3, max. 6.7 W
• Material :Aluminum alloy body
• Dimension :

Ø76.6 mm × 164.4 mm (Ø3 × 6.5\")"

• Package Dimension :234 mm × 120 mm × 117 mm (9.2" × 4.7" × 4.6")
• Weight :

-L: Approx. 410 g (0.9 lb.), -LUF: Approx. 430 g (0.9 lb.)

• With Package Weight :

-L: Approx. 630 g (1.4 lb.), -LUF: Approx. 650 g (1.4 lb.)

• Storage Conditions :-30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)
• Startup and Operating Conditions :-30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)
• Language :English, Ukrainian
• General Function :Heartbeat,anti-banding,mirror,password protection,password reset via email

• Approval
• EMC :

CE-EMC: EN 55032:2015+A1:2020, EN 50130-4:2011+A1:2014, EN IEC 61000-3-2:2019+A1:2021, EN 61000-3-3:2013+A1:2019+A2:2021,

RCM: AS/NZS CISPR 32: 2015,

KC: KN32: 2015, KN35: 2015

• Safety :

UL: UL 62368-1,

CB: IEC 62368-1: 2014+A11,

CE-LVD: EN 62368-1: 2014/A11: 2017,

BIS: IS 13252 (Part 1): 2010/IEC 60950-1: 2005

• Environment :

CE-RoHS: 2011/65/EU,

WEEE: 2012/19/EU,

Reach: Regulation (EC) No 1907/2006

• Protection :IP67: IEC 60529-2013,IK10: IEC 62262:2002
